La tabella taglie va usata soltanto come referenza. Per favore controlla tramite il tuo rivenditore autorizzato Giant/LIV per determinare la tua taglia corretta. Le taglie disponibli possono variare da paese a paese.
Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
-
- S
- 162 cm
172 cm
-
- M
- 169 cm 179 cm
-
- L
- 176 cm 186 cm
-
- XL
- 183 cm 193 cm
Selection of a button will change the units measurement displayed throughout the entire sizing guide section.
|
|
S |
M |
L |
XL |
| A |
LUNGHEZZA TUBO SELLA (mm) |
410 |
435 |
490 |
545 |
| B |
ANGOLO TUBO SELLA |
74,0° |
73,5° |
73,0° |
73,0° |
| C |
LUNGHEZZA TUBO ORIZZONTALE (mm) |
585 |
600 |
610 |
630 |
| D |
LUNGHEZZA TUBO STERZO (mm) |
140 |
155 |
170 |
185 |
| E |
ANGOLO STERZO |
69,0° |
69,5° |
69,5° |
69,5° |
| F |
RAKE FORCELLA (mm) |
51 |
51 |
51 |
51 |
| G |
AVANCORSA (mm) |
88 |
84 |
84 |
84 |
| H |
INTERASSE (mm) |
1147 |
1151 |
1156 |
1177 |
| I |
LUNGHEZZA CARRO POSTERIORE (mm) |
455 |
470 |
470 |
470 |
| J |
DROP MOVIMENTO CENTRALE (mm) |
60 |
60 |
60 |
60 |
| K |
STACK (mm) |
665 |
682 |
696 |
710 |
| L |
REACH (mm) |
394 |
398 |
397 |
413 |
| M |
ALTEZZA STAND OVER (mm) |
682 |
670 |
650 |
649 |
| N |
LARGHEZZA MANUBRIO C/C (mm) |
690 |
690 |
690 |
690 |
| O |
LUNGHEZZA ATTACCO MANUBRIO (mm) |
60 |
80 |
100 |
100 |
| P |
LUNGHEZZA PEDIVELLA (mm) |
170 |
170 |
170 |
170 |
| Q |
DIMENSIONE RUOTE |
29" |
29" |
29" |
29" |
-
Motore
Giant SyncDrive Pro 2 85Nm, powered by Yamaha, PedalPlus 6-Sensor technology
-
Comando
Giant RideControl Ergo 2 remote, Smart Assist automatic mode, 5 support levels, USB-C (10W)
-
Display
Giant RideDash EVO, high-angle visibility, 3" full color LCD display, on-board navigation
-
Batteria
Giant EnergyPak 800Wh, 22700 Lithium cell technology, Aluminium casing with highest safety standard (EN50604)
-
Caricatore
Giant EnergyPak 6A smart charger, 60% charge in 3:00h
-
Connettività
Giant RideControl App enabled ANT+ wireless display signal with e-bike profile
-
Taglie
S, M, L, XL
-
Colorazioni
Truffle
-
Telaio
ALUXX aluminum, Overdrive 1.8" - 1.5" head tube, integrated battery, integrated KSA40 kickstand mount
-
Forcella
SR Suntour XCR34 Air Boost, 100mm travel, Hydraulic Lockout, 15x110mm AH Axle
-
Manubrio
Giant Contour Comfort Riser 31.8x690mm
-
Manopole
Gant Connect Ergo Max Cork w/bar-end
-
Attacco manubrio
Giant Contour EVO integrated 16⁰ (S/M:80mm L/XL/XXL 100mm)
-
Reggisella
Giant 30.9mm, 2-bolt Micro Adjustable, Forged Aluminium
-
Sella
Selle Royal Vivo Ergo Moderate Unisex
-
Pedali
Aluminum Platform
-
Cambio
Shimano Deore, LinkGlide
-
Deragliatore Posteriore
Shimano Deore LinkGlide, 10-speed, Shadow+
-
Freni
Shimano BR-MT410, hydraulic disc, 180mm
-
Comandi Freno
Shimano Deore
-
Pacco Pignoni
Shimano LinkGlide, CS-LG400-10, 11-43T, 10-speed
-
Catena
Shimano LinkGlide, CN-LG500
-
Guarnitura
Forged Alloy Direct spider/chainguard 46T Steel narrow/wide chainring
-
Cerchi
eX25, Tubeless Ready, 622x25 Aluminium
-
Mozzi
Giant eTracker, [F] 110x15 [R] 148x12
-
Raggi
Stainless steel, e-bike optimized
-
Copertoni
Crosscut Gravel 1, 700x57c, Foldable, Tubeless Ready
-
Illuminazione
Recon E HL100 StVZO [F] AXA NYX 6-12V E-bike tail light with brake sensor [R]
-
Lucchetto
KSA40 direct mount kickstand
-
Portapacchi
MIK HD rack. System bag & basket compatible
-
Parafango / Paracatena
Alluminum Fenders
-
Peso
Peso Indicativo 27,6 Kg (M)
ANYTOUR X E+ 3 GIANT TG. S
